Product Summary
The FGA180N33ATDTU is a high-performance IGBTs.
Parametrics
FGA180N33ATDTU Parametrics:
Packaging
Tube
IGBT Type
Trench
Voltage - Collector Emitter Breakdown (Max)
330V
Current - Collector (Ic) (Max)
180A
Current - Collector Pulsed (Icm)
450A
Vce(on) (Max) @ Vge, Ic
1.4V @ 15V, 40A
Power - Max
390W
Switching Energy
-
Input Type
Standard
Gate Charge
169nC
Td (on/off) @ 25°C
-
Test Condition
-
Reverse Recovery Time (trr)
27ns
Package / Case
TO-3P-3, SC-65-3
Mounting Type
Through Hole
Supplier Device Package
TO-3PN
Dynamic Catalog
Standard IGBTs
Features
FGA180N33ATDTU Features:
?High Current Capability
?Low saturation voltage: VCE(sat) =1.03V @ IC = 40A
?High input impedance
?RoHS compliant
