Product Summary

The PTZTE2520B is a high-performance Zener diode,which is used for Voltage regulation.

Parametrics

PTZTE2520B Parametrics:

Packaging Tape & Reel (TR)
Voltage - Zener (Nom) (Vz) 20.8V
Tolerance ±6%
Current - Reverse Leakage @ Vr 10μA @ 15V
Power - Max 1W
Impedance (Max) (Zzt) 14 Ohm
Voltage - Forward (Vf) (Max) @ If -
Operating Temperature -
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package PMDS
Dynamic Catalog PTZTE25 Zener Diode
Other Names PTZTE2520B-ND
PTZTE2520BTR

Features

PTZTE2520B Features:

1) Small power mold type. (PMDS)
2) High ESD tolerance
