Product Summary

The 74HC11D is a high-performance Logic IC.

Parametrics

74HC11D Parametrics:

Packaging   Tape & Reel (TR)
Logic Type AND Gate
Number of Circuits 3
Number of Inputs 3
Features -
Voltage - Supply 2 V ~ 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V ~ 1.8 V
Logic Level - High 1.5 V ~ 4.2 V
Max Propagation Delay @ V, Max CL 17ns @ 6V, 50pF
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Supplier Device Package 14-SO
Package / Case 14-SOIC (0.154", 3.90mm Width)
Dynamic Catalog 74HC
Other Names 568-8129-2
74HC11D,653-ND
74HC11D-T
74HC11D-T-ND
933714290653

Features

74HC11D Features:

  • ? Input levels: CMOS levell
  • ? ESD protection:


? HBM JESD22-A114F exceeds 2000 V

? MM JESD22-A115-A exceeds 200 V
