V300A12H500AL

V300A12H500AL, DC-DC Converter Module, 100 Vdc, 1550 Vrms, 99W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $71.00~77.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $71.00~77.50

PartNumber:: V300A12H500AL

Brand:: Vicor Corporation - Vicor | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Winnie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-03

From Other Seller

Part Number:V300A12H500AL
US $71.00 - 77.50
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The V300A12H500AL is a DC-DC Converter Module. The V300A12H500AL uses 2nd Generation power processing, control and packaging technologies to provide the performance, flexibility and cost effectiveness expected of a mature power component. For example, a plated-cavity core transformer couples widely separated primary and secondary windings, resulting in low in-toout parasitic capacitance and noise. High frequency ZCS/ZVS switching, advanced power semiconductor packaging and thermal management provide high power density with low temperature gradients. Extensive use of silicon integration results in 1/3 the V300A12H500ALcount of a 1st Generation converter.

Parametrics

V300A12H500AL absolute maximum ratings: (1)+In to –In voltage: -0.5 to +75.0 Vdc; (2)+In to –In voltage: 100 Vdc; (3)PC to –In voltage: -0.5 to +7.0 Vdc; (4)PR to –In voltage: -0.5 to +7.0 Vdc; (5)+Out to –Out voltage: -0.5 to +16.0 Vdc; (6)+Sense to –Out voltage: -0.5 to +16.0 Vdc; (7)–Sense to –Out voltage: 1.0 Vdc; (8)SC to –Out voltage: -0.5 to +1.5 Vdc; (9)Isolation voltage (in to out): 3000 Vrms; (10)Isolation voltage (in to base): 1550 Vrms; (11)Isolation voltage (out to base): 500 Vrms; (12)Storage temperature (C–Grade): -40 to +125 ℃; (13)Operating temperature (C–Grade): -20 to +100 ℃ Baseplate; (14)Pin soldering temperature: 500 (260)°F (℃)<5 sec;wave solder; (15)Pin soldering temperature: 750 (390)°F (℃)<7 sec; hand solder.

Features

V300A12H500AL features: (1)DC input range: 36 - 75V; (2)Input surge withstand: 100V for 100ms; (3)DC output: 12V; (4)Programmable output: 10 to 110%; (5)Regulation: ±0.2% no load to full load; (6)Efficiency: 85.7%; (7)Maximum operating temperature: 100℃ at full load; (8)Power density: 99W/cubic inch; (9)Height above board: 0.43 in. (10,9 mm); (10)Parallelable, with N+M fault tolerance; (11)Low noise ZCS/ZVS architecture.
