The AM26LS32ACNSR is a high-performance  Interface IC.

Parametrics

AM26LS32ACNSR Parametrics:

Packaging   Tape & Reel (TR)
Type Receiver
Protocol RS422, RS423
Number of Drivers/Receivers 0/4
Duplex -
Receiver Hysteresis 50mV
Data Rate -
Voltage - Supply 4.75 V ~ 5.25 V
Operating Temperature 0°C ~ 70°C
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209", 5.30mm Width)
Supplier Device Package 16-SO
Dynamic Catalog RS-422, RS-423 Differential Line Receivers
Other Names 296-6790-2

Features

AM26LS32ACNSR Features:

? AM26LS32A Devices Meet or Exceed the Requirements of ANSI TIA/EIA-422-B, TIA/EIA-423-B, and ITU

  Recommendations V.10 and V.11
? AM26LS32A Devices Have ±7-V Common-Mode Range With ±200-mV Sensitivity
? AM26LS33A Devices Have ±15-VCommon-Mode Range With ±500-mV Sensitivity
? Input Hysteresis . . . 50 mV Typical
? Operate From a Single 5-V Supply
? Low-Power Schottky Circuitry
? 3-State Outputs
? Complementary Output-Enable Inputs
? Input Impedance . . . 12 kΩ Minimum
? Designed to Be Interchangeable With Advanced Micro Devices AM26LS32? and AM26LS33?
