Product Summary

The HEF4066BT is a high-performance  Interface IC.

Parametrics

HEF4066BT Parametrics:

Packaging   Tape & Reel (TR)
Function Switch
Circuit 4 x SPST - NO
On-State Resistance 155 Ohm
Voltage Supply Source Single Supply
Voltage - Supply, Single/Dual (±) 3 V ~ 15 V
Current - Supply 4μA
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154", 3.90mm Width)
Supplier Device Package 14-SO
Dynamic Catalog Switch
Other Names 568-2266-2
933372970653
HEF4066BT653
HEF4066BTD-T

Features

HEF4066BT Features:

  • Fully static operation
  • ? Standardized symmetrical output characteristics
  • ? Inputs and outputs are protected against electrostatic effects
  • ? Operates across the automotive temperature range ?40 °C to +125 °C
  • ? Complies with JEDEC standard JESD 13-B
