IRF2807ZPBF

MOSFET N-CH, 75V, 75A, TO-220AB, IRF2807ZPBF, International Rectifier

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.48~0.57 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.48~0.57

PartNumber:: IRF2807ZPBF

Brand:: International Rectifier - IR | Pack: TO | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Winnie's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-06

From Other Seller

Part Number:IRF2807ZPBF
US $0.48 - 0.57
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
QM75DY-H

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRF2807ZPBF is a HEXFET Power MOSFET. This HEXFET Power MOSFET utilizes the latest processing techniques to achieve extremely low on-resistance per silicon area. Additional features of this design are a 175℃ junction operating temperature, fast switching speed and improved repetitive avalanche rating. These features combine to make the IRF2807ZPBF an extremely efficient and reliable device for use in a wide variety of applications.

Parametrics

IRF2807ZPBF absolute maximum ratings: (1)Continuous Drain Current, VGS @ 10V (Silicon limited): 89A; (2)Continuous Drain Current, VGS @ 10V:63A; (3)Continuous Drain Current, VGS @ 10V (Package limited):75A; (4)Pulsed Drain Current:350A; (5)Power Dissipation:170W; (6)Linear Derating Factor:1.1W/℃ ; (7)Gate-to-Source Voltage:±20V; (8)Single Pulse Avalanche Energy:160mJ ; (9)Single Pulse Avalanche Energy Tested Value:200mJ; (10)Operating Junction and Storage Temperature Range:-55℃ to +175℃; (11)Soldering Temperature, for 10 seconds:300℃ (1.6mm from case ).

Features

IRF2807ZPBF features: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Dynamic dv/dt Rating; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Repetitive Avalanche Allowed up to Tjmax; (7)Lead-Free.
