Product Summary

The L293DD is a high-performance PUSH-PULL FOUR CHANNEL DRIVER WITH DIODES.

Parametrics

L293DD Parametrics:

Packaging Tube
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge, (4) Quad
Interface Parallel
Applications General Purpose
Current - Output 600mA
Voltage - Supply 4.5 V ~ 36 V
Voltage - Load 4.5 V ~ 36 V
Operating Temperature -40°C ~ 150°C
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295", 7.50mm Width)
Supplier Device Package 20-SOIC
Other Names 497-1390-5
497-4552-5
497-4552-5-ND
E-L293DD

Features

L293DD Features:


  • 600mA OUTPUT CURRENT CAPABILITY PER CHANNEL
  • 1.2A PEAK OUTPUT CURRENT (non repetitive) PER CHANNEL
  • ENABLE FACILITY
  • OVERTEMPERATURE PROTECTION
  • LOGICAL "0" INPUT VOLTAGE UP TO 1.5 V(HIGH NOISE IMMUNITY)
  • INTERNAL CLAMP DIODES


Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
L293DD
L293DD

STMicroelectronics

Motor / Motion / Ignition Controllers & Drivers Push-Pull 4-Channel

Data Sheet

0-1: $2.12
1-10: $1.92
10-100: $1.60
100-250: $1.46
L293DD013TR
L293DD013TR

STMicroelectronics

Motor / Motion / Ignition Controllers & Drivers Push-Pull 4-Channel

Data Sheet

0-1: $2.18
1-10: $1.75
10-100: $1.59
100-250: $1.44
L293DDWP
L293DDWP

Texas Instruments

IC QUADRUPLE HALF-H DRIVER

Data Sheet

Negotiable
