Product Summary

The ZXMN2A01FTA is a TRENCH MOSFET. It combines the benefits of low on-resistance with fast switching speed. It is ideal for high efficiency, low voltage, power management applications. Its package is SOT-23.

Parametrics

Absolute maximum ratings: (1)Drain-Source Voltage, VDSS: 20 V; (2)Gate Source Voltage, VGS: 12 V; (3)Pulsed Drain Current, IDM: 10 A; (4)Continuous Source Current (Body Diode), IS: 1.05 A; (5)Pulsed Source Current (Body Diode), ISM: 10 A; (6)Operating and Storage Temperature Range, Tj, Tstg: -55 to +150 ℃.

Features

Features: (1)Low on-resistance; (2)Fast switching speed; (3)Low threshold; (4)Low gate drive; (5)SOT23 package.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ZXMN2A01FTA
ZXMN2A01FTA
Diodes Inc.
MOSFET 20V N-Chnl UMOS
Data Sheet
0-1: $0.33
1-10: $0.26
10-100: $0.17
100-500: $0.15
