Product Summary
The TDA7296 is a monolithic integrated circuit in Multiwatt15 package, intended for use as audio class AB amplifier in Hi-Fi field
applications (Home Stereo, self powered loudspeakers, Topclass TV).
Parametrics
TDA7296 Parametrics:(1)Package:Multiwatt15V (2)Supply Voltage (No Signal):±35V (3)Output Peak Current:5A
(3)Power Dissipation Tcase = 70°C : 50W (4)Operating Ambient Temperature Range: 0 to 70°C
Features
TDA7296 Features:(1)MULTIPOWER BCD TECHNOLOGY (2)VERY HIGH OPERATING VOLTAGE RANGE (±35V)
(3)DMOS POWER STAGE (4)HIGH OUTPUT POWER (UP TO 60W MUSIC POWER) (5)MUTING/STAND-BY FUNCTIONS
(6)NO SWITCH ON/OFF NOISE (7)NO BOUCHEROT CELLS (8)VERY LOW DISTORTION (9)VERY LOW NOISE
(10)SHORT CIRCUIT PROTECTION (11)THERMAL SHUTDOWN
