Product Summary
The EPCS4SI8N is a high-performance Serial Configuration (EPCS) Devices.
Parametrics
EPCS4SI8N Parametrics:
Packaging
Tube
Programmable Type
In System Programmable
Memory Size
4Mb
Voltage - Supply
2.7 V ~ 3.6 V
Operating Temperature
-40°C ~ 85°C
Package / Case
8-SOIC (0.154", 3.90mm Width)
Supplier Device Package
8-SOIC
Dynamic Catalog
EPCS
Other Names
544-1379-5
EPCS4SI8N-ND
Features
EPCS4SI8N Features:
- Supports active serial (AS) x1 configuration scheme
- Easy-to-use four-pin interface
- Low cost, low pin count, and non-volatile memory
- Low current during configuration and near-zero standby mode current
- 2.7-V to 3.6-V operation
- 8-pin small-outline integrated circuit (SOIC) package
- Write protection support for memory sectors using status register bits
- ISP support with USB-Blaster?, EthernetBlaster, or ByteBlaster II download cables
- In-system programming (ISP) support with SRunner software driver
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 EPCS4SI8N |
Altera |
IC CONFIG DEVICE 4MBIT 8-SOIC |
Data Sheet |
|
|
||||||
