Product Summary
The LM2904MX is a high-performance Dual Operational Amplifier.
Parametrics
LM2904MX Parametrics:
Packaging
Cut Tape (CT)
Amplifier Type
General Purpose
Number of Circuits
2
Output Type
-
Slew Rate
0.3 V/μs
Gain Bandwidth Product
-
-3db Bandwidth
-
Current - Input Bias
45nA
Voltage - Input Offset
2.9mV
Current - Supply
800μA
Current - Output / Channel
30mA
Voltage - Supply, Single/Dual (±)
3 V ~ 26 V, ±1.5 V ~ 13 V
Operating Temperature
-40°C ~ 85°C
Mounting Type
Surface Mount
Package / Case
8-SOIC (0.154", 3.90mm Width)
Supplier Device Package
8-SOIC
Dynamic Catalog
General Purpose
Other Names
LM2904MXFSCT
Features
LM2904MX Features:
- Internally Frequency Compensated for Unity Gain
- Large DC Voltage Gain: 100dB
- Input Common Mode Voltage Range Includes Ground
- Large Output Voltage Swing: 0V DC to Vcc -1.5V DC
- Power Drain Suitable for Battery Operation.
Diagrams
