Product Summary
The OPA2376AIDGKR is a high-performance Amplifier IC.
Parametrics
OPA2376AIDGKR Parametrics:
Packaging
Tape & Reel (TR)
Amplifier Type
General Purpose
Number of Circuits
2
Output Type
Rail-to-Rail
Slew Rate
2 V/μs
Gain Bandwidth Product
5.5MHz
-3db Bandwidth
-
Current - Input Bias
0.2pA
Voltage - Input Offset
5μV
Current - Supply
760μA
Current - Output / Channel
50mA
Voltage - Supply, Single/Dual (±)
2.2 V ~ 5.5 V, ±1.1 V ~ 2.75 V
Operating Temperature
-40°C ~ 125°C
Mounting Type
Surface Mount
Package / Case
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package
8-VSSOP
Dynamic Catalog
General Purpose
Other Names
296-22630-2
Features
OPA2376AIDGKR Features:
?LOW NOISE:7.5nV/√Hz at 1kHz
?0.1Hz to 10Hz NOISE:0.8μVPP
?QUIESCENTCURRENT:950μA(max)
?LOW OFFSET VOLTAGE:25μV(max)
?SINGLE-SUPPLY OPERATION
?SUPPLY VOLTAGE:2.2V to 5.5V
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OPA2376AIDGKR |
Texas Instruments |
Operational Amplifiers - Op Amps Prec Lo Noise Lo Quies Current Op Amp |
Data Sheet |
|
|
||||||||||||
|
OPA2376AIDGKRG4 |
Texas Instruments |
Operational Amplifiers - Op Amps Prec Lo Noise Lo Quies Current Op Amp |
Data Sheet |
|
|
||||||||||||
