Product Summary

The OPA699IDR is a high-performance Wideband, High Gain VOLTAGE LIMITING AMPLIFIER.

Parametrics

OPA699IDR Parametrics:

Packaging Tape & Reel (TR)
Amplifier Type Voltage Feedback
Number of Circuits 1
Output Type -
Slew Rate 1400 V/μs
Gain Bandwidth Product 1GHz
-3db Bandwidth 260MHz
Current - Input Bias 3μA
Voltage - Input Offset 1.5mV
Current - Supply 15.5mA
Current - Output / Channel 120mA
Voltage - Supply, Single/Dual (±) 5 V ~ 12 V, ±2.5 V ~ 6 V
Operating Temperature -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
For Use With
296-19589-ND - PCB DEMO GENERIC FOR 8SOIC OPAMP

Features

OPA699IDR Features:


  •  HIGH LINEARITY NEAR LIMITING
  •  FAST RECOVERY FROM OVERDRIVE: 1ns
  •  LIMITING VOLTAGE ACCURACY: ±10mV
  •  –3dB BANDWIDTH (G = +6): 260MHz
  •  GAIN BANDWIDTH PRODUCT: 1000MHz
  •  STABLE FOR G ≥ +4V/V
  •  SLEW RATE: 1400V/μs


Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
OPA699IDR
OPA699IDR
Texas Instruments
High Speed Operational Amplifiers Wideband High Gain Vltg Limiting
Data Sheet
0-1855: $1.58
1855-2000: $1.52
2000-2500: $1.52
OPA699IDRG4
OPA699IDRG4
Texas Instruments
High Speed Operational Amplifiers Wideband High Gain Vltg Limiting
Data Sheet
0-1855: $1.58
1855-2000: $1.52
2000-2500: $1.52
