The SN74ALS04BN is a high-performance  Logic IC.

Parametrics

SN74ALS04BN Parametrics:

Packaging   Tube
Logic Type Inverter, Buffer
Number of Circuits 6
Number of Inputs 1
Features -
Voltage - Supply 4.5 V ~ 5.5 V
Current - Quiescent (Max) -
Current - Output High, Low 400μA, 8mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 11ns @ 5V, 50pF
Operating Temperature 0°C ~ 70°C
Mounting Type Through Hole
Supplier Device Package 14-PDIP
Package / Case 14-DIP (0.300", 7.62mm)
Dynamic Catalog 74ALS
Other Names 296-1481
296-1481-5

Features

SN74ALS04BN Features:

  • hex inverter
