Product Summary

The ADG407BPZ is monolithic CMOS analog multiplexers. The ADG407BPZ is designed on an enhanced LC2MOS process

that provides low power dissipation yet gives high switching speed and low on resistance.




Parametrics

ADG407BPZ Parametrics: (1)Series: LC2MOS (2)Packaging:Tube (3)Function:Multiplexer (4)Circuit:2 x 8:1

(4)On-State Resistance:90 Ohm   (5)Voltage Supply Source:Single, Dual Supply (6)Current - Supply:100μA

(7)Voltage - Supply, Single/Dual (±):12V, ±15V    (8)Operating Temperature:-40°C ~ 85°C

(9)Mounting Type:Surface Mount  (10)Supplier Device Package:28-PLCC (11.51x11.51)

Features

ADG407BPZ Features:(1) 44 V supply maximum ratings  (2) VSS to VDD analog signal range

(3)Low on resistance (80 Ω maximum)    (4)Low power (5)Fast switching:① tON < 160 ns ② tOFF < 150 ns

(6)Break-before-make switching action


Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ADG407BPZ
ADG407BPZ

IC MULTIPLEXER DUAL 8X1 28PLCC
Data Sheet
0-1: $7.06
1-10: $6.42
10-100: $5.45
100-250: $4.97
250-500: $4.65
500-1000: $4.28
