Product Summary
The AME8500BEETAA27Z is a 2.70V UProcessor Supervisory device. It allows the user to customize the CPU reset function without any external components. The user has a large choice of reset voltage thresholds, reset time intervals, and output driver configurations, all of which are preset at the factory. The AME8500BEETAA27Z monitors the power supply voltage of µP based systems. The applications of the AME8500BEETAA27Z are Portable electronics, Power supplies, Computer peripherals, Data acquisition systems, Applications using CPUs, Consumer electronics.
Parametrics
AME8500BEETAA27Z absolute maximum ratings: (1)Supply Voltage:7 V; (2)ESD Classification:B; (3)Input Current, VDD:20 mA; (4)Output Current, RESET, ResetB:20 mA; (5)Rate of Rise, VDD:100 V/μs.
Features
AME8500BEETAA27Z features: (1)Small packages: SOT-23, SOT-89; (2)11 voltage threshold options; (3)Tight voltage threshold tolerance:±1.50%; (4)5 reset interval options; (5)4 output configuration options; (6)Wide temperature range:-40℃ to 85℃; (7)Low temperature coefficient:100ppm/℃(max); (8)Low quiescent current < 3.0μA.
Diagrams
 |
