Product Summary

The CD4093BM96 is a high-performance  Logic IC.

Parametrics

CD4093BM96 Parametrics:

Packaging   Tape & Reel (TR)
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Features Schmitt Trigger
Voltage - Supply 3 V ~ 18 V
Current - Quiescent (Max) 4μA
Current - Output High, Low 3.4mA, 3.4mA
Logic Level - Low 0.9 V ~ 4 V
Logic Level - High 3.6 V ~ 10.8 V
Max Propagation Delay @ V, Max CL 130ns @ 15V, 50pF
Operating Temperature -55°C ~ 125°C
Mounting Type Surface Mount
Supplier Device Package 14-SOIC
Package / Case 14-SOIC (0.154", 3.90mm Width)
Dynamic Catalog 4000B - Texas Instruments
Other Names 296-25956-2
CD4093BM96-ND
