Product Summary

These devices contain six independent inverters.

Parametrics

SN74LS04N Parametrics:

Packaging Tube
Logic Type Inverter, Buffer
Number of Circuits 6
Number of Inputs 1
Features -
Voltage - Supply 4.75 V ~ 5.25 V
Current - Quiescent (Max) -
Current - Output High, Low 400μA, 8mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 15ns @ 5V, 15pF
Operating Temperature 0°C ~ 70°C
Mounting Type Through Hole
Supplier Device Package 14-PDIP
Package / Case 14-DIP (0.300", 7.62mm)
Dynamic Catalog 74LS
Other Names 296-1629
296-1629-5

Features

SN74LS04N Features:
